3D-EM

Cellular electron microscopy has been a key technique for understanding the cell’s core elements and mechanisms since the 1950s. Electron microscopic methods have laid the foundation for a number of Nobel Prizes and have given us much of the basic understanding of human cells’ overall structure, physiology and mechanisms—basically the foundation of all modern medicine.

In recent years, electron microscopy has undergone extremely rapid development through a combination of significantly better optics, sample processing, detectors and image processing. The development has given rise to the so-called “Resolution Revolution,” which in recent years has gradually increased the average resolution of biological preparations significantly. Part of the discoveries and methodology resulted in a Nobel Prize to Richard Henderson, Jaques Dubochet and Joachim Frank. At the beginning of this revolution, a visionary decision of the then Karolinska Institutet’s (KI’s) leadership was made to build premises for a future electron microscopy center nearby the Biomedicum building at the KI Solna campus. These premises have now been built specifically for high-end biomedical electron microscopy. During 2019-2020 we will equip the newly built KI 3D-EM center with the best possible equipment and thereby enable a much broader group of KI researchers to utilize the enormous advances in electron microscopy in recent years.

Picture of microscope Krios G3i and the Talos 120C

Instruments available

Electron microscopes

Available for use:

120 kV LaB6microscope: Talos 120C G2 with Ceta-D detector

300 kV cold-FEG microscope: Krios G3i with Gatan K3 detector and Ceta-D detector.
Aquilos 2 cryo-FIB-SEM

Leica SP8 cryo-confocal microscope



Sample preparation

Available:

  • Leica Microtome 1
  • Leica Microtome 2
  • Vitrobot Mk 1
  • Vitrobot Mk 4
  • Glow discharger
  • Plasma cleaner

Access and booking

Only registered users can have an access to the facility. Registration is to be done at 3D-EM Core Facility Service and must be approved by PI of the user. The PI provides each user with project number to facilitate the payment via iLab booking system.

Teaching and training

We will arrange courses and workshops. However, users are encouraged to receive personal training followed by a test that will open the access to the 120 kV Talos microscope. Please contact Sergej.Masich@ki.se for more details.

Prices for service

Prices for service and access for equipment currently available (including local overhead):

Prices for service and access for equipment currently available (including local overhead):
Internal External* Companies*
Aquilos 2 RT 3h 1050 1050 5000
Aquilos 2 RT/cryo 24h 2500 2500 15000
Krios 3h 2000 2000 20000
Krios 24h 5000 5000 50000
Talos 120C 3h 600 600 6000
SP8 cryo-confocal 24h 800 800 8000

*external/company usage of the Aquilos2, Krios and SP8 cryo-confocal requires facility manager/director support for setup/startup and that is billed at 550 SEK per hour. Training time is free for KI personnel but charged at 550 SEK per hour for external/companies. International academic customers pay double hourly microscope fees, all other costs same.
